UC28023DWRG4

在庫數 393

小計金額 $0.00000

仕様よくある質問

Package / Case：SOIC
Surface Mount：YES
Number of Pins：16
Weight：473.692182mg
Voltage - Input (Nom)：15V
Frequency(Max)：1MHz
Packaging：Tape and Reel
JESD-609 Code：e4
Moisture Sensitivity Level (MSL)：2 (1 Year)
Number of Terminations：16
ECCN Code：EAR99
Terminal Finish：Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature：105°C
Min Operating Temperature：-40°C
Additional Feature：CAN ALSO BE CONFIGURED IN PEAK CURRENT OR AVERAGE CURRENT MODE
Terminal Position：DUAL
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Frequency：1MHz
Time@Peak Reflow Temperature-Max (s)：NOT SPECIFIED
Pin Count：16
Number of Outputs：1
Qualification Status：Not Qualified
Temperature Grade：INDUSTRIAL
Max Supply Voltage：30V
Analog IC - Other Type：SWITCHING CONTROLLER
Current - Output：200mA
Voltage - Output：13V
Topology：Boost, Flyback, Push-Pull
Control Mode：VOLTAGE-MODE
Frequency - Switching：1MHz
Control Technique：PULSE WIDTH MODULATION
Rise Time：60ns
Fall Time (Typ)：60 ns
Nominal Input Voltage：30V
Max Duty Cycle：100 %
Duty Cycle (Max)：90 %
Height Seated (Max)：2.65mm
Width：7.5mm
RoHS Status：RoHS Compliant
Lead Free：Lead Free
