ODC-5

TE Connectivity
I/O Relay Modules
Input/Output Modules 4-Pin
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Mounting Type：PCB Mount
Product Weight：35(g)
Category：Input/Output Modules
Mounting：Screw Mount
Lead Free Status / RoHS Status：--
Voltage-Input：5VDC (3 ~ 8VDC)
Current-Input：18mA
Operating Temperature Max Deg. C：80C
Load Current (Max)：3A(A)
I/O Isolation Voltage (V)：4000Vrms
Load Voltage (Max)：60VDC
Load Voltage (Min)：3VDC
Mounting Styles：Through Hole
Agency Approvals：UL/CSA
Operating Temperature Min Deg. C：-30C
Rad Hardened：No
Package Style：Module
Dimensions：43.18 x 15.2 x 31.8mm
Output Device：Transistor
Control Voltage Range：3 → 8 V dc
Unit Weight：1.104004 oz
Factory Pack QuantityFactory Pack Quantity：100
Part # Aliases：4-1393028-4
Manufacturer：TE Connectivity
Brand：TE Connectivity / P&B
RoHS：Details
Package：Tray
Base Product Number：ODC
Mfr：TE Connectivity Potter & Brumfield Relays
Product Status：Active
Operating Temperature：-30 to 80 °C
Series：ODC
Packaging：Tray
Part Status：Active
Type：Input/Output Modules
Color：Red
Subcategory：I/O Modules
Technology：Electromechanical
Depth：15.2mm
Style：Standard
Pin Count：4
Termination Style：PC Terminals
Output Voltage：3 V to 60 V
Output Type：DC
Output Current：3 A
Current - Output：0.01 ~ 3A
Input Type：DC
Voltage - Output：3 ~ 60VDC
Input Voltage (Min)：3VDC
Input Voltage (Max)：8VDC
Terminal Type：PC PIN
Product Type：I/O Modules
Operating Temperature Range：-30 → +80°C
Isolation：4000 V
Turn On Time：0.10ms
Input Current：18MA(mA)
Turn Off Time：0.75ms
Contact Configuration：SPST
Product：DC Input Modules
Case Color：Red
Features：Hold Down Screw
Input Voltage：5VDC(V)
Product Category：I/O Modules
Module Type：Output Module
Height：31.8mm
Length：43.18mm
