TE Connectivity
Cable and Cord Grips
Conn Housing PL 6 POS 9.14mm Crimp ST Loose Piece
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：Production (Last Updated: 5 days ago)
Factory Lead Time：13 Weeks
Contact Plating：-
Mount：Free Hanging
Mounting Type：CABLE OR PANEL
Material：Polyamide (PA)
Housing Material：Nylon
Body Material：Nylon
Body Orientation：Straight
Base/Housing Material：Nylon
Harmonized Code：
ECCN：EAR99
Itar Registered：No
Dim：(L x W x H) 18.1 x 32.4 x 31.4 mm
Pins per row：3
Manufacturer part #：180906
Connector contact surface：Tin plated
Industrial packaging：No
Content：1pc(s)
Case material：Polyamide
No. of rows：2
Total number of pins：6
CS：6.35mm
Pin shape：Rectangular
Factory colour：Ecru
Voltage Rating Max：250VDC/250VAC
Number of Contact Rows：2
Product Depth (mm)：18.1(mm)
Operating Temp Range：-30C to 105C
Pitch (mm)：9.14(mm)
Unit Weight：0.141096 oz
Factory Pack QuantityFactory Pack Quantity：1200
Mounting Styles：In-Line
Contact Materials：-
Manufacturer：TE Connectivity
Brand：TE Connectivity / AMP
Tradename：FASTON
RoHS：Details
Tab Width：6.3mm
Pitch Spacing：9.14mm
For Use With：0.250 Tab Terminals
Manufacturer Lifecycle Status：ACTIVE (Last Updated: 5 days ago)
Contact Finish Mating：NOT SPECIFIED
Rohs Code：Yes
Manufacturer Part Number：180906
Number of Rows Loaded：1
Part Life Cycle Code：Active
Ihs Manufacturer：TE CONNECTIVITY LTD
Risk Rank：1.58
Operating Temperature：-30 to 105 °C
Series：FASTIN-FASTON
Packaging：Box
Pbfree Code：Yes
Termination：Quick Connect
Connector Type：Tab
Type：180906
Number of Positions：6
Max Operating Temperature：105 °C
Min Operating Temperature：-30 °C
Color：Natural
Number of Rows：2
Gender：Plug
Additional Feature：FASTIN-FASTON
Subcategory：Terminals
MIL Conformance：NO
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Mixed Contacts：NO
Option：GENERAL PURPOSE
Pitch：9.1400 mm
Total Number of Contacts：6
Orientation：Straight
Depth：32.4 mm
Reach Compliance Code：compliant
Current Rating：28 A
Termination Style：Crimp
Number of Contacts：6(POS)
Contact Gender：Socket (Female)
Housing Color：Natural
Empty Shell：YES
Brand Name：AMP
Insulation Resistance：1 GΩ
Number of Circuits：6
Max Voltage Rating (AC)：250 V
Termination Type：CRIMP
Max Voltage Rating (DC)：250 V
Insulation：Insulated
Product Type：Terminals
Stud/Tab Size：6.35 mm
Product：Accessories
Mounting Angle：Straight
Product Category：Terminals
Product Length：31.4 mm
Product Length (mm)：31.4(mm)
Width：32.4mm
Height：31.4mm
Length：18.1mm
Product Height (mm)：32.4(mm)
REACH SVHC：Unknown
Radiation Hardening：No
Flammability Rating：UL94 V-2
Lead Free：Lead Free
