PT280024

TE Connectivity
Power Relays, Over 2 Amps
Dust Cover
Electromechanical Relay DPDT 24A 24VDC 777Ohm Plug-In
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Package / Case：Dust Cover
Mounting Type：Socketable
Relay Construction：Non-Latching
Supplier Package：Dust Cover
Minimum Dropout Voltage：2.4 Vdc
Contact Materials：Gold/Nickel-Silver
CoilResistance：777 Ohm
Mounting：Plug-In
Pick-up Voltage (Max)：18VDC
Product Depth (mm)：22.5(mm)
LED Indicator：No
Operating Temp Range：-40C to 70C
Mounting Styles：Plug-In
Dropout Volt：2.4VDC
Seal：FLUX SEALED
Maximum Power Rating：3KVA
Rad Hardened：No
Unit Weight：1.058219 oz
Factory Pack QuantityFactory Pack Quantity：10
Part # Aliases：1393154-3
Manufacturer：TE Connectivity
Brand：TE Connectivity
RoHS：Details
Package：Bulk
Base Product Number：PT280
Mfr：TE Connectivity Potter & Brumfield Relays
Product Status：Active
Operating Temperature：-40 to 70 °C
Series：*
Packaging：Box
Part Status：Active
Type：Industrial Relay
Subcategory：Relays
Pin Count：8
Termination Style：Quick Connect
Contact Current Rating：24(A)
Contact Termination：Quick Connect
Contact Form：2 Form C
Relay Type：General Purpose
Product Type：General Purpose Relays
Operate Time：15 ms
Coil Voltage：24 VDC
Coil Type：Non-Latching
Switching Voltage：400 VAC
Coil Current：30.89(mA)
Release Time：10 ms
Must Operate Voltage：18 VDC
Contact Rating (Current)：12 A
Must Release Voltage：2.4 VDC
Coil Voltage (DC)：24
Seal Rating：-
Coil Insulation：Class F
Contact Arrangement：DPDT
Product：Power Relays
Features：-
Coil Suppression Diode：No
Product Category：General Purpose Relays
Product Length：28 mm
Voltage Rating (VAC)：400(V)
Product Length (mm)：28(mm)
Width：22.5 mm
Height：29 mm
Length：28 mm
Product Height (mm)：35(mm)
