1-292215-6

TE Connectivity
Rectangular Connectors - Adapters
Conn Coupler Header M/M 16 POS 1.5mm ST Panel Mount Loose Piece
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：12 Weeks
Contact Plating：Tin
Body Orientation：Straight
Base/Housing Material：Nylon 66
Contact Materials：Brass
Mounting：Panel Mount
Voltage, Rating：50 V
Maximum Operating Temperature：+ 105 C
Unit Weight：0.041870 oz
Minimum Operating Temperature：- 30 C
Factory Pack QuantityFactory Pack Quantity：400
Mounting Styles：Through Hole
Manufacturer：TE Connectivity
Brand：TE Connectivity / AMP
Tradename：Common Termination
RoHS：Details
Contact Finish Mating：TIN
Rohs Code：Yes
Manufacturer Part Number：1-292215-6
Number of Rows Loaded：1
Part Life Cycle Code：Active
Ihs Manufacturer：TE CONNECTIVITY LTD
Risk Rank：1.73
Operating Temperature：-30 to 105 °C
Series：Mini CT
Packaging：Bulk
JESD-609 Code：e3
Pbfree Code：Yes
Connector Type：BOARD CONNECTOR
Type：Shrouded
Number of Positions：16 Position
Applications：Wire-to-Panel
Number of Rows：1 Row
Gender：2 Plug
Additional Feature：PANEL MOUNTABLE
Subcategory：Headers & Wire Housings
MIL Conformance：NO
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Contact Type：Pin (Male)
Mixed Contacts：NO
Option：GENERAL PURPOSE
Pitch：1.5000 mm
Total Number of Contacts：16
Terminal Pitch：1.5 mm
Reach Compliance Code：compliant
Current Rating：2 A
Termination Style：Solder Pin
Contact Gender：Pin (Male)
UL Flammability Code：94V-0
Housing Color：White
Brand Name：AMP
Contact Finish Termination：Tin (Sn)
Product Type：Headers & Wire Housings
Product：Headers
Mounting Angle：Straight
Product Category：Headers & Wire Housings
Product Length：30.5 mm
