2-435802-1

TE Connectivity
DIP Switches
DIP & SIP Switches, Switch, Gold, Black Housing, Polyester GF, Sealed, 11 Switch, -55 – 105 °C, DIP, Alcoswitch DIP
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：Production (Last Updated: 6 days ago)
Factory Lead Time：6 Weeks
Contact Plating：Tin
Mount：Through Hole
Mounting Type：Through Hole
Surface Mount：NO
Mounting Feature：THROUGH HOLE-STRAIGHT
Housing Material：Polyester
Actuator Material：THERMOPLASTIC
Center Contact Plating：GOLD OVER NICKEL
Center Contact Material：COPPER ALLOY
Terminal Material：COPPER ALLOY
End Contact Material：COPPER ALLOY
End Contact Plating：GOLD OVER NICKEL
Body Orientation：Straight
Termination Method：Solder
Base/Housing Material：Polymer
Contact Materials：Copper Alloy
Mounting：Through Hole
Factory Pack QuantityFactory Pack Quantity：10
Mounting Styles：PCB Mount
Actuator Style：Piano
Manufacturer：TE Connectivity
Illuminated：Non-Illuminated
Brand：TE Connectivity / Alcoswitch
RoHS：N
Actuator：Piano
Voltage Rating (DC)：50 V
Package：Tube
Base Product Number：435802
Mfr：TE Connectivity ALCOSWITCH Switches
Product Status：Active
Package Description：ROHS COMPLIANT
Insulator Material：GLASS FILLED POLYESTER
Operating Temperature-Min：-55 °C
Operating Temperature-Max：105 °C
Rohs Code：No
Manufacturer Part Number：2-435802-1
ActuatorColor：WHITE
Part Life Cycle Code：Active
Ihs Manufacturer：TE CONNECTIVITY LTD
ElectricalLife：7000 Cycle(s)
Risk Rank：2.13
Dielectric Withstand Volts：500VDC V
Operating Temperature：-55 to 125 °C
Series：7000
Termination：PC Pins
ECCN Code：EAR99
Type：Switch
Number of Positions：11 Position
Max Operating Temperature：105 °C
Min Operating Temperature：-55 °C
Gender：Receptacle
Additional Feature：LOW PROFILE
HTS Code：8536.50.90.40
Subcategory：Switches
Pitch：2.5400 mm
Orientation：Straight
Terminal Pitch：2.54 mm
Reach Compliance Code：compliant
Termination Style：Through Hole
Body Length or Diameter：29.97 mm
Body Breadth：9.65 mm
Actuator Type：Piano
Housing Color：Gray
Lead Length：3.556 mm
Brand Name：Alcoswitch
Circuit：SPST
Switch Function：SPST
Contact Resistance：0.1 mΩ
Insulation Resistance：100000000000 Ω
Contact Current(DC)-Max：0.025 A
ELV：Compliant
Contact Voltage(DC)-Max：24 V
Termination Type：SOLDER
Max Current Rating：100 mA
Throw Configuration：SPST
Max Voltage Rating (DC)：24 V
Switch Type：DIP
Contact Current Rating：1.5 A
Contact Form：SPST
Product Type：DIP Switches
Contact Timing：BREAK-BEFORE-MAKE
Contact (DC) Max Rating R Load：
Number of Switch Sections：11
PCB Hole Count：22
Contact Function：ON-OFF
Switch Action：MOMENTARY
Washable：Yes
Actuator Level：Raised
Body Color：BLACK
Mounting Angle：Right Angle
Terminal Length：0.14 inch
Product Category：DIP Switches / SIP Switches
Product Length：114.3 mm
Height：7.366 mm
Length：29.97 mm
Body Height：7.37 mm
Radiation Hardening：No
Flammability Rating：UL94 V-0
Lead Free：Lead Free
