2N5795

Microchip
Transistors - Bipolar (BJT) - Arrays
TO-78-6 Metal Can
Bipolar Transistors - BJT BJTs
Date Sheet

在庫數 11

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：Production (Last Updated: 2 months ago)
Contact Plating：Lead, Tin
Mount：Through Hole
Mounting Type：Through Hole
Package / Case：TO-78-6 Metal Can
Surface Mount：NO
Supplier Device Package：TO-78-6
Number of Terminals：8
Transistor Element Material：SILICON
Factory Pack QuantityFactory Pack Quantity：1
Manufacturer：Microchip
Brand：Microchip Technology
RoHS：N
Package：Bulk
Current-Collector (Ic) (Max)：600mA
Base Product Number：2N5795
Mfr：Microchip Technology
Product Status：Active
Package Style：CYLINDRICAL
Package Body Material：METAL
Reflow Temperature-Max (s)：NOT SPECIFIED
Operating Temperature-Max：200 °C
Rohs Code：No
Transition Frequency-Nom (fT)：200 MHz
Manufacturer Part Number：2N5795
Turn-on Time-Max (ton)：50 ns
Package Shape：ROUND
Number of Elements：2
Part Life Cycle Code：Active
Ihs Manufacturer：MICROSEMI CORP
Turn-off Time-Max (toff)：140 ns
Risk Rank：5.23
Packaging：Bulk
Operating Temperature：-65°C ~ 175°C (TJ)
Series：-
JESD-609 Code：e0
Pbfree Code：No
ECCN Code：EAR99
Temperature Coefficient：600.0000 ppm/°C
Resistance：10 mOhm
Terminal Finish：TIN LEAD
Max Operating Temperature：175 °C
Min Operating Temperature：-65 °C
Subcategory：Transistors
Power Rating：2.0000 W
Max Power Dissipation：600 mW
Technology：Si
Terminal Position：BOTTOM
Terminal Form：WIRE
Peak Reflow Temperature (Cel)：NOT SPECIFIED
Reach Compliance Code：unknown
JESD-30 Code：O-MBCY-W8
Qualification Status：Not Qualified
Configuration：SEPARATE, 2 ELEMENTS
Power - Max：600mW
Polarity/Channel Type：PNP
Product Type：BJTs - Bipolar Transistors
Transistor Type：2 PNP (Dual)
Collector Emitter Voltage (VCEO)：60 V
Max Collector Current：600 mA
DC Current Gain (hFE) (Min) @ Ic, Vce：40 @ 150mA, 10V
Current - Collector Cutoff (Max)：10µA (ICBO)
JEDEC-95 Code：TO-78
Vce Saturation (Max) @ Ib, Ic：1.6V @ 50mA, 500mA
Voltage - Collector Emitter Breakdown (Max)：60V
Frequency - Transition：-
Collector Base Voltage (VCBO)：60 V
Resistance Tolerance：1
Collector Current-Max (IC)：0.6 A
DC Current Gain-Min (hFE)：40
Collector-Emitter Voltage-Max：60 V
Product Category：Bipolar Transistors - BJT
Product Length：6.35
Product Width：3.15
