25AA256-I/STG

Microchip
Memory
EEPROM 32kx8 - 1.8V Lead Free Package
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Surface Mount：YES
Number of Pins：8
Number of Terminals：8
Qualification：AEC-Q200
Voltage, Rating：75 V
Package Description：4.40 MM, PLASTIC, MO-153, TSSOP-8
Package Style：SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Moisture Sensitivity Levels：1
Number of Words Code：32000
Package Body Material：PLASTIC/EPOXY
Package Equivalence Code：TSSOP8,.25
Operating Temperature-Min：-40 °C
Reflow Temperature-Max (s)：40
Operating Temperature-Max：85 °C
Rohs Code：Yes
Manufacturer Part Number：25AA256-I/STG
Clock Frequency-Max (fCLK)：10 MHz
Number of Words：32768 words
Supply Voltage-Nom (Vsup)：2.5 V
Package Code：TSSOP
Package Shape：RECTANGULAR
Manufacturer：Microchip Technology Inc
Part Life Cycle Code：Active
Ihs Manufacturer：MICROCHIP TECHNOLOGY INC
Risk Rank：5.3
Part Package Code：TSSOP
JESD-609 Code：e3
Pbfree Code：Yes
ECCN Code：EAR99
Temperature Coefficient：25.0000 ppm/°C
Resistance：49.9 Ohm
Terminal Finish：Matte Tin (Sn)
HTS Code：8542.32.00.51
Subcategory：EEPROMs
Power Rating：0.2500 W
Technology：CMOS
Terminal Position：DUAL
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Terminal Pitch：0.65 mm
Resistor Type：Thin Film
Reach Compliance Code：compliant
JESD-30 Code：R-PDSO-G8
Qualification Status：Not Qualified
Power Supplies：2/5 V
Temperature Grade：INDUSTRIAL
Operating Mode：SYNCHRONOUS
Supply Current-Max：0.005 mA
Organization：32KX8
Seated Height-Max：1.1 mm
Memory Width：8
Standby Current-Max：0.000001 A
Memory Density：262144 bit
Parallel/Serial：SERIAL
Memory IC Type：EEPROM
Resistance Tolerance：0.5
Serial Bus Type：SPI
Endurance：1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC)：5 ms
Data Retention Time-Min：200
Write Protection：HARDWARE/SOFTWARE
Voltage - Supply (Max)：5.5 V
Voltage - Supply (Min)：1.8 V
Product Length：1.55 mm
Product Width：0.85 mm
Width：3 mm
Length：4.4 mm
