5-1634503-1

TE Connectivity
Coaxial Connectors (RF)
Conn ZDC/BNC RCP 0Hz to 4GHz 50Ohm Solder ST Thru-Hole Gold Individual
Date Sheet

在庫數 1150

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：Production (Last Updated: 9 months ago)
Contact Plating：Gold
Mounting Type：PCB Mount
Mount：PCB, Through Hole
Shell Material：ZINC
Dielectric Material：Polymethylpentene
Body Material：Zinc
Mounting Option 1：LOCKING
Panel Mount：NO
Terminate To：PCB
Body Orientation：Straight
Termination Method：Solder
Contact Materials：Phosphor Bronze
Mounting：Through Hole
Product Depth (mm)：11(mm)
Operating Temp Range：-55C to 85C
Product Diameter (mm)：11(mm)
Mounting Styles：Through Hole
Rad Hardened：No
Insulation Materials：Polymethylpentene
Maximum Operating Temperature：+85°C
Minimum Operating Temperature：-55°C
Schedule B：8536694010, 8536694010/8536694010, 8536694010/8536694010/8536694010, 8536694010/8536694010/8536694010/8536694010
Voltage Rating (DC)：500 V
Manufacturer Lifecycle Status：ACTIVE (Last Updated: 9 months ago)
Tail Length：4.4958 mm
RoHS：Compliant
Cable Types：-
Contact Finish Mating：NOT SPECIFIED
Insulator Material：POLYMETHYLPENTENE
Operating Temperature-Min：-55 °C
Operating Temperature-Max：85 °C
Rohs Code：Yes
Operating Frequency (Max)：4 GHz
Manufacturer Part Number：5-1634503-1
Manufacturer：TE Connectivity
Part Life Cycle Code：Active
Samacsys Description：AMP - TE CONNECTIVITY - 5-1634503-1 - RF COAXIAL, BNC, STRAIGHT JACK, 50OHM
Ihs Manufacturer：TE CONNECTIVITY LTD
Risk Rank：1.72
Operating Temperature：-55 to 85 °C
Packaging：Box
Series：Greenpar
Pbfree Code：Yes
Termination：Solder
Connector Type：BNC Coaxial
Type：ZDC/BNC
Number of Positions：1
Max Operating Temperature：85 °C
Min Operating Temperature：-67 °C
Gender：RCP
Fastening Type：Bayonet
Subcategory：RF BNC Connectors
MIL Conformance：NO
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Option：GENERAL PURPOSE
Total Number of Contacts：1
Orientation：Vertical
Depth：11 mm
Reach Compliance Code：compliant
Frequency：4 GHz
Shell Finish：NICKEL
Termination Style：Solder
Reliability：COMMERCIAL
Number of Contacts：1
Contact Gender：FEMALE
Operating Frequency：0, 4 GHz
Body Depth：0.539 inch
Brand Name：AMP
Polarity：Normal, Standard
Contact Style：COAX
Contact Resistance：1.5 mΩ
Insulation Resistance：5 GΩ
Body/Shell Style：SOCKET
ELV：Compliant
Termination Type：SOLDER
Dielectric Withstanding Voltage：2100VAC V
Coupling Type：BAYONET
Impedance：50(ohm)
Number of Ports：1
Body Plating：Nickel
Durability：50 Cycles
Sealable：No
Max Frequency：4 GHz
Insertion Loss：0.2 dB
Body Finish：Nickel
VSWR：1.3
Outside Diameter：14.529 mm
Characteristic Impedance：50 Ω
Product：PCB Receptacles
Terminal Length：0.177 inch
Body Style：Straight
Product Length：13.7 mm
RF Series：BNC
IP Rating：-
Product Length (mm)：13.7(mm)
Height：13.7 mm
Length：13.7 mm
PCB Thickness：3.2004 mm
REACH SVHC：No SVHC
Radiation Hardening：No
