Home Connectors, Interconnects Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) 2-5767004-4
画像はあくまで参考です。
2-5767004-4
-
TE Connectivity
-
Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
- Conn High Speed Fine Pitch Connector RCP 114 POS 2.54mm/0.64mm Solder ST Thru-Hole/SMD Tube
Date Sheet
在庫數 5645
小計金額 $0.00000
仕様 よくある質問
- Factory Lead Time：26 Weeks
- Contact Plating：Gold
- Mounting Type：BOARD
- Housing Material：Liquid Cryst Polymer
- Mounting Option：DETENT
- Board Mounting Option：PEG
- Body Orientation：Straight
- Termination Method：Solder
- Base/Housing Material：LCP (Liquid Crystal Polymer)
- Contact Materials：Copper Alloy
- Voltage Rating Max：30VAC
- Number of Contact Rows：2
- Product Depth (mm)：8.72(mm)
- Contact Resistance Max：10(mohm)
- Operating Temp Range：-55C to 125C
- Mounting Styles：TH/SMT
- Pitch (mm)：2.54/0.64(mm)
- RoHS：Details
- Brand：TE Connectivity / AMP
- Manufacturer：TE Connectivity
- Factory Pack QuantityFactory Pack Quantity：10
- Minimum Operating Temperature：- 55 C
- Unit Weight：0.075980 oz
- Maximum Operating Temperature：+ 125 C
- Voltage, Rating：30 V
- Contact Finish Mating：NOT SPECIFIED
- Body Length：2 inch
- Insulator Material：LIQUID CRYSTAL POLYMER (LCP)
- Operating Temperature-Min：-55 °C
- Operating Temperature-Max：125 °C
- Rohs Code：Yes
- Manufacturer Part Number：2-5767004-4
- Number of Rows Loaded：2
- Part Life Cycle Code：Active
- Ihs Manufacturer：TE CONNECTIVITY LTD
- Number Of Connectors：ONE
- Risk Rank：2.11
- Manufacturer Series：5767004
- Operating Temperature：-55 to 125 °C
- Packaging：Box/Tube
- Series：Mictor
- JESD-609 Code：e3
- Pbfree Code：Yes
- ECCN Code：EAR99
- Connector Type：BOARD STACKING CONNECTOR
- Type：HiSpeedFinePitchConn
- Number of Positions：114 Position
- Number of Rows：2 Row
- Gender：Receptacle
- Additional Feature：ELV & ROHS COMPLIANT, TUBE PKG
- HTS Code：8536.69.40.40
- Subcategory：Board to Board & Mezzanine Connectors
- MIL Conformance：NO
- DIN Conformance：NO
- IEC Conformance：NO
- Filter Feature：NO
- Mixed Contacts：NO
- Option：GENERAL PURPOSE
- Pitch：2.5400, 0.6400 mm
- Terminal Pitch：0.64 mm
- Reach Compliance Code：compliant
- Current Rating：11.5 A
- Reference Standard：UL
- Termination Style：Solder Pin
- Reliability：COMMERCIAL
- Number Of PCB Rows：2
- Number of Contacts：3POWER/114SIGNAL(POS)
- PCB Contact Pattern：RECTANGULAR
- Body Breadth：0.272 inch
- Housing Color：Black
- Body Depth：0.24 inch
- Brand Name：AMP
- Rated Current (Signal)：1 A
- Contact Style：BELLOWED TYPE
- Contact Resistance：10 mΩ
- Insulation Resistance：10000 MOhms
- Row Spacing：7.0866 mm
- Mating Contact Pitch：0.025 inch
- Body/Shell Style：RECEPTACLE
- Termination Type：SURFACE MOUNT
- Polarization Key：POLARIZED HOUSING
- Dielectric Withstanding Voltage：500VAC V
- Durability：25 Cycles
- Contact Pattern：RECTANGULAR
- Insertion Force-Max：1.112 N
- Withdrawl Force-Min：.139 N
- Insulator Color：BLACK
- Product Type：Board to Board & Mezzanine Connectors
- Current Rating (Max)：11.5/CONTACT(A)
- Product：Receptacles
- Mounting Angle：Vertical
- Product Category：Board to Board & Mezzanine Connectors
- Product Length：50.8 mm
- Product Length (mm)：50.8(mm)
- Plating Thickness：30u inch
- Stack Height：6 mm
- Product Height (mm)：6.1(mm)
