画像はあくまで参考です。
969973-7
-
TE Connectivity
-
Rectangular Connectors - Headers, Receptacles, Female Sockets
- Conn Socket Strip RCP 14 POS 2.54mm Solder ST SMD T/R
Date Sheet
在庫數 1413
小計金額 $0.00000
仕様 よくある質問
- Contact Plating：Gold
- Housing Material：Liquid Crystal Polymer (LCP)
- Body Orientation：Straight
- Termination Method：Solder
- Base/Housing Material：LCP (Liquid Crystal Polymer)
- Contact Materials：Phosphor Bronze
- Mounting：Surface Mount
- Voltage Rating Max：250VAC
- Number of Contact Rows：2
- Product Depth (mm)：7.65(mm)
- Contact Resistance Max：12(mohm)
- Operating Temp Range：-65C to 125C
- Mounting Styles：Surface Mount
- Pitch (mm)：2.54(mm)
- Pitch Spacing：2.54mm
- Maximum Operating Temperature：+ 125 C
- Unit Weight：0.037179 oz
- Minimum Operating Temperature：- 65 C
- Factory Pack QuantityFactory Pack Quantity：700
- Manufacturer：TE Connectivity
- Brand：TE Connectivity
- Tradename：AMPMODU
- RoHS：Details
- Operating Temperature：-65 to 125 °C
- Packaging：Tape and Reel
- Series：AMPMODU HV-100
- Type：Socket Strip
- Number of Positions：14 Position
- Applications：Board-to-Board
- Number of Rows：2 Row
- Gender：Receptacle
- Subcategory：Headers & Wire Housings
- Pitch：2.5400 mm
- Termination Style：Solder
- Number of Contacts：14(POS)
- Contact Gender：Socket (Female)
- Mating Post Length：2.54 mm
- Product Type：Headers & Wire Housings
- Current Rating (Max)：3/Contact(A)
- Product：Headers
- Mounting Angle：Straight
- Product Category：Headers & Wire Housings
- Product Height (mm)：6.2(mm)
