1986375-5
-
TE Connectivity
-
Terminal Blocks - Headers, Plugs and Sockets
- Conn Terminal Block F 5 POS 3.81mm Screw ST Cable Mount 11A/Contact
Date Sheet
在庫數 0
小計金額 $0.00000
仕様 よくある質問
- Lifecycle Status：Production (Last Updated: 2 days ago)
- Contact Plating：Tin
- Mount：Cable, Free Hanging
- Mounting Type：Cable Mount
- Material：Nylon
- Housing Material：Polyamide 6/6
- Body Orientation：Straight
- Termination Method：Screw
- Wire Size：30 to 14, 30 AWG
- Base/Housing Material：Polyamide 66
- Contact Materials：Phosphor Bronze
- Mounting：Cable Mount
- Number of Contact Rows：1
- Contact Pitch (mm)：3.81(mm)
- Product Depth (mm)：10.35(mm)
- Operating Temp Range：-40C to 110C
- Mounting Styles：Cable
- Operating Voltage (Max)：300VAC
- Rad Hardened：No
- Voltage, Rating：300 V
- Manufacturer Lifecycle Status：ACTIVE (Last Updated: 2 days ago)
- Voltage Rating (AC)：300 V
- RoHS：Compliant
- Maximum Operating Temperature：+110°C
- Minimum Operating Temperature：-40°C
- Fused：No
- Wire Orientation：Side
- Unit Weight：0.147198 oz
- Factory Pack QuantityFactory Pack Quantity：150
- Wire Gauge Min：30 AWG
- Wire Gauge Max：14 AWG
- Manufacturer：TE Connectivity
- Brand：TE Connectivity
- Operating Temperature：-40 to 110 °C
- Packaging：Bulk
- Termination：Screw
- Connector Type：Plug
- Type：Terminal Block
- Number of Positions：5
- Max Operating Temperature：110 °C
- Min Operating Temperature：-40 °C
- Color：Green
- Number of Rows：1
- Gender：F
- Subcategory：Terminal Blocks
- Pitch：3.8100 mm
- Orientation：Straight
- Current Rating：11 A
- Termination Style：Screw
- Number of Contacts：5(POS)
- Housing Color：Green
- Wire Gauge：14-30(AWG)
- Voltage：300 V
- ELV：Compliant
- Number of Circuits：5
- Max Voltage Rating (AC)：300 V
- Max Current Rating：11 A
- Number of Levels：1
- Current：11 A
- Wire Gauge (Max)：30 AWG
- Wire Gauge (Min)：14 AWG
- Wire/Cable Gauge：14 AWG
- Number of Poles：5
- Number of Ways：5
- Thread Size：M2
- Product Type：Pluggable Terminal Blocks
- Connector System：Wire-to-Board
- Number of Positions Per Level：5
- Current Rating (Max)：11/Contact(A)
- Connection Method：Screw
- Product：Plugs
- Mounting Angle：Vertical
- Product Category：Pluggable Terminal Blocks
- Product Length：19.05 mm
- Product Length (mm)：19.05(mm)
- Product Height (mm)：19.2(mm)
- REACH SVHC：Unknown
- Radiation Hardening：No
- Flammability Rating：UL94 V-0
