770967-2

TE Connectivity
Rectangular Connectors - Headers, Male Pins
Conn Power PIN 3 POS 4.14mm Solder RA Thru-Hole 3 Terminal 1 Port
Date Sheet

在庫數 0

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：Production (Last Updated: 1 week ago)
Contact Plating：Gold
Mount：Through Hole
Housing Material：Nylon
Number of Terminals：3
PCB Mounting Orientation：Right Angle
Body Orientation：Right Angle
Termination Method：Solder
Base/Housing Material：Nylon
Contact Materials：Brass
Mounting：Through Hole
Pitch Spacing：4.14mm
Voltage, Rating：600 V
Housing Gender：Plug
Unit Weight：0.042011 oz
Factory Pack QuantityFactory Pack Quantity：200
Mounting Styles：PCB
Manufacturer：TE Connectivity
Brand：TE Connectivity / AMP
Tradename：MATE-N-LOK
RoHS：N
Circuit Applications：Power
Approvals：CSA
Series：MATE-N-LOK
Packaging：Bulk
Termination：Solder
Connector Type：Pin
Number of Positions：3 Position
Max Operating Temperature：221 °C
Min Operating Temperature：-67 °C
Color：White
Number of Rows：1 Row
Gender：Pin
Fastening Type：Ramp
Subcategory：Pin & Socket Connectors
Pitch：4.1400 mm
Orientation：Right Angle
Current Rating：9.5 A
Termination Style：Through Hole
Number of Contacts：3
Contact Gender：Pin (Male)
Housing Color：White
Operating Supply Voltage：600 V
Contact Style：Pin
Number of Circuits：3
Max Voltage Rating (AC)：600 V
Plating：Gold
Number of Ports：1
Accessory Type：-
Max Voltage Rating (DC)：600.6 kV
Sealable：No
Contact Current Rating：9.5 A
Number of Power Positions：3
Number of Signal Positions：0
Product Type：Pin & Socket Connectors
Connector System：Wire-to-Board
Contact Retention：Without
VDE Tested：Yes
Product：Headers
Product Category：Pin & Socket Connectors
Product Length：15.29 mm
Width：5.72 mm
Height：12.7 mm
Length：9.86 mm
Plating Thickness：760 nm
REACH SVHC：Unknown
Radiation Hardening：No
Flammability Rating：UL 94 V-0
Lead Free：Contains Lead
