画像はあくまで参考です。
MTM106DPC
-
TE Connectivity
-
Toggle Switches
- Switch Toggle ON None ON SPDT Short Bat Toggle PC Pins 6A 250VAC 28VDC PC Mount with Threads
Date Sheet
在庫數 92
小計金額 $0.00000
仕様 よくある質問
- Factory Lead Time：20 Weeks
- Mounting Type：Panel Mount
- Contact Plating：Gold
- Surface Mount：NO
- Mounting Feature：THROUGH HOLE-STRAIGHT
- Housing Material：Polyester
- Number of Terminals：3
- Actuator Material：Copper Alloy, Chrome Plated
- Center Contact Plating：GOLD
- Terminal Material：BRASS
- End Contact Plating：GOLD
- Switch Configuration：ON None ON
- Contact Materials：Gold Flash/Silver
- Pole Throw Configuration：SPDT
- Mounting：PC Mount with Threads
- Voltage Rating DC：28V
- ElectricalLife：80,000 Cycles
- Voltage Rating AC：125V
- Operating Temperature Max Deg. C：80C
- Body Orientation：Straight
- Seal Description：EPOXY
- Product Depth (mm)：8(mm)
- Actuator Length (mm)：6.9(mm)
- Contact Resistance Max：20(mohm)
- Operating Temp Range：-20C to 80C
- Dielectric Strength：1500VAC
- Seal Location：TERMINALS
- Actuator Style：SHORT BAT LEVER
- ActuatorColor：CHROME
- Operating Temperature Min Deg. C：-20C
- AC Voltage Rating (Max)：250
- DC Voltage Rating (Max)：28
- Bushing Size：1/4-40
- Maximum Operating Temperature：+ 80 C
- Unit Weight：0.160003 oz
- Minimum Operating Temperature：- 20 C
- Factory Pack QuantityFactory Pack Quantity：25
- Mounting Styles：Panel Mount
- Part # Aliases：4-1437559-6
- Manufacturer：TE Connectivity
- Illuminated：Non-Illuminated
- Terminal Seal：Sealed
- Brand：TE Connectivity / P&B
- RoHS：Details
- Actuator：Bat
- Package：Bulk
- Base Product Number：MTM106
- Mfr：TE Connectivity ALCOSWITCH Switches
- Product Status：Active
- Insulator Material：THERMOSET 94V-0
- Operating Temperature-Min：-20 °C
- Operating Temperature-Max：80 °C
- Rohs Code：Yes
- Manufacturer Part Number：MTM106DPC
- Part Life Cycle Code：Active
- Ihs Manufacturer：TE CONNECTIVITY LTD
- Risk Rank：2.05
- Dielectric Withstand Volts：1500VRMS V
- Operating Temperature：-20 to 80 °C
- Series：MTM Green
- Packaging：Bulk
- JESD-609 Code：e4
- Part Status：Active
- ECCN Code：EAR99
- Type：Toggle Switch
- Terminal Finish：Gold (Au)
- Additional Feature：PANEL MOUNTABLE
- HTS Code：8536.50.90.65
- Subcategory：Switches
- Current Rating (Amps)：6A (AC), 4A (DC)
- Ingress Protection：--
- Reach Compliance Code：compliant
- Termination Style：PC Pin
- Body Length or Diameter：13 mm
- Body Breadth：8 mm
- Actuator Type：Standard Round
- Brand Name：Alcoswitch
- Circuit：SPDT
- Switch Function：On-On
- Panel Cutout Dimensions：Circular - 6.40mm Dia
- Contact Resistance：0.02 mΩ
- Insulation Resistance：1000(Mohm)
- Contact Current(DC)-Max：4 A
- Illumination Voltage (Nominal)：--
- Illumination Type, Color：--
- Sealing：EPOXY TERMINAL SEALED
- Contact Voltage(DC)-Max：28 V
- Termination Type：SOLDER
- Illumination：Non-Illuminated
- Mechanical Life：150000
- Switch Type：TOGGLE SWITCH
- Contact Form：SPDT
- Thread Size：1/4-40
- Bushing Thread：1/4-40
- Terminal Type：PC Pins
- Product Type：Toggle Switches
- Illumination Color：-
- Contact Current(AC)-Max：6 A
- Contact (AC) Max Rating R Load：
- Contact Timing：BREAK-BEFORE-MAKE
- Contact (DC) Max Rating R Load：
- Contact Voltage(AC)-Max：125 V
- Current Rating (Max)：6(A)
- Contact Function：ON-ON
- Switch Action：LATCHED
- Solderability：HAND
- Bushing Length：0.32 inch
- Actuator Angle：26 deg
- Operating Force-Max：14.71 N
- Washability：SOLVENT
- Actuator Finish：NICKEL
- Bushing Type：THREADED
- Lamp Type：-
- Mounting Angle：Vertical
- Features：Epoxy Sealed Terminals
- Compliance：-
- Terminal Length：0.19 inch
- Product Category：Toggle Switches
- Product Length (mm)：13(mm)
- Body Height：10 mm
- Actuator Length：6.90mm
- Product Height (mm)：26.5(mm)
- Flammability Rating：UL 94 V-0
