TYN412

在庫數 6000

小計金額 $0.00000

仕様よくある質問

Surface Mount：NO
Contact plating：gold-plated
Number of pins：35
Number of Terminals：3
Exterior Housing Material：1
Rohs Code：Yes
Part Life Cycle Code：Obsolete
Ihs Manufacturer：STMICROELECTRONICS
Package Description：FLANGE MOUNT, R-PSFM-T3
Leakage Current-Max：3 mA
Operating Temperature-Max：125 °C
Operating Temperature-Min：-40 °C
Package Body Material：PLASTIC/EPOXY
Package Shape：RECTANGULAR
Package Style：FLANGE MOUNT
Type of connector：pin strips
Connector：socket
Kind of connector：female
Spatial orientation：straight
Contacts pitch：2.54mm
Electrical mounting：THT
Connector pinout layout：1x35
Gross weight：1.68 g
Operating temperature：-40...163°C
JESD-609 Code：e3
ECCN Code：EAR99
Terminal Finish：MATTE TIN
HTS Code：8541.30.00.80
Terminal Position：SINGLE
Terminal Form：THROUGH-HOLE
Reach Compliance Code：not_compliant
Current rating：1.5A
JESD-30 Code：R-PSFM-T3
Qualification Status：Not Qualified
Configuration：SINGLE
JEDEC-95 Code：TO-220AB
Trigger Device Type：SCR
On-state Current-Max：12000 A
Repetitive Peak Off-state Voltage：400 V
Rated voltage：60V
Non-Repetitive Pk On-state Cur：120 A
Critical Rate of Rise of Off-State Voltage-Min：200 V/us
Repetitive Peak Reverse Voltage：400 V
RMS On-state Current-Max：12 A
Holding Current-Max：30 mA
DC Gate Trigger Current-Max：15 mA
DC Gate Trigger Voltage-Max：1.5 V
Profile：beryllium copper
Circuit Commutated Turn-off Time-Nom：70 μs
Repetitive Peak Off-state Leakage Current-Max：10 μA
Plating thickness：0.254µm
Flammability rating：UL94V-0
