Home Connectors, Interconnects Rectangular Connectors - Headers, Receptacles, Female Sockets CLP-134-02-F-DH-A
画像はあくまで参考です。
CLP-134-02-F-DH-A
-
Samtec Inc.
-
Rectangular Connectors - Headers, Receptacles, Female Sockets
- Conn Socket Strip SKT 68 POS 1.27mm Solder RA SMD T/R
Date Sheet
在庫數 0
小計金額 $0.00000
仕様 よくある質問
- Factory Lead Time：3 Weeks
- Mounting Type：Surface Mount, Right Angle
- Contact Shape：Square
- Board Mounting Option：PEG
- Contact Finish Mating：Gold
- Contact Materials：Phosphor Bronze
- Insulation Materials：Liquid Crystal Polymer (LCP)
- Operating Temperature：-55°C~125°C
- Packaging：Tube
- Series：CLP
- Published：2016
- JESD-609 Code：e3
- Part Status：Active
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Termination：Solder
- Connector Type：Receptacle
- Number of Positions：68
- Number of Rows：2
- Gender：Female
- Additional Feature：LOW PROFILE
- Fastening Type：Push-Pull
- Voltage - Rated DC：340V
- MIL Conformance：NO
- DIN Conformance：NO
- IEC Conformance：NO
- Filter Feature：NO
- Contact Type：Female Socket
- Mixed Contacts：NO
- Option：GENERAL PURPOSE
- Current Rating (Amps)：3.3A per Contact
- Total Number of Contacts：68
- Insulation Height：0.135 3.43mm
- Style：Board to Board
- Number of Positions Loaded：All
- Pitch - Mating：0.050 1.27mm
- Insulation Color：Black
- Number of Conductors：ONE
- Voltage - Rated AC：240V
- Reliability：COMMERCIAL
- Body Length or Diameter：1.717 inch
- Row Spacing - Mating：0.050 (1.27mm)
- Number Of PCB Rows：2
- Contact Finish - Post：Tin
- PCB Contact Pattern：RECTANGULAR
- Body Breadth：0.135 inch
- Mating Contact Pitch：0.05 inch
- PCB Contact Row Spacing：3.9878 mm
- Features：Board Guide
- Plating Thickness：FLASH inch
- Contact Finish Thickness - Mating：3.00μin 0.076μm
- Material Flammability Rating：UL94 V-0
- RoHS Status：ROHS3 Compliant
- Lead Free：Lead Free
