Home Connectors, Interconnects Rectangular Connectors - Headers, Receptacles, Female Sockets CLP-140-02-L-D-BE-A-P-TR
画像はあくまで参考です。
CLP-140-02-L-D-BE-A-P-TR
-
Samtec Inc.
-
Rectangular Connectors - Headers, Receptacles, Female Sockets
- Conn Socket Strip SKT 80 POS 1.27mm Solder ST SMD T/R
Date Sheet
在庫數 28
小計金額 $0.00000
仕様 よくある質問
- Factory Lead Time：3 Weeks
- Mounting Type：Surface Mount
- Contact Shape：Square
- Board Mounting Option：PEG
- Contact Finish Mating：Gold
- Contact Materials：Phosphor Bronze
- Insulation Materials：Liquid Crystal Polymer (LCP)
- Operating Temperature：-55°C~125°C
- Packaging：Tape & Reel (TR)
- Series：CLP
- JESD-609 Code：e3
- Pbfree Code：yes
- Part Status：Active
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Termination：Solder
- Connector Type：Receptacle, Bottom Entry
- Number of Positions：80
- Number of Rows：2
- Gender：Female
- Additional Feature：BOTTOM ENTRY, LOW PROFILE
- Fastening Type：Push-Pull
- Voltage - Rated DC：340V
- MIL Conformance：NO
- DIN Conformance：NO
- IEC Conformance：NO
- Filter Feature：NO
- Contact Type：Female Socket
- Mixed Contacts：NO
- Option：GENERAL PURPOSE
- Current Rating (Amps)：3.3A per Contact
- Total Number of Contacts：80
- Insulation Height：0.084 2.14mm
- Style：Board to Board
- Number of Positions Loaded：All
- Pitch - Mating：0.050 1.27mm
- Insulation Color：Black
- Number of Conductors：ONE
- Voltage - Rated AC：240V
- Reliability：COMMERCIAL
- Row Spacing - Mating：0.050 (1.27mm)
- Number Of PCB Rows：2
- Contact Finish - Post：Tin
- PCB Contact Pattern：RECTANGULAR
- UL Flammability Code：94V-0
- Body Depth：0.09 inch
- Mating Contact Pitch：0.05 inch
- Features：Board Guide, Pick and Place
- Plating Thickness：10μin
- Contact Finish Thickness - Mating：10.0μin 0.25μm
- Material Flammability Rating：UL94 V-0
- Radiation Hardening：No
- RoHS Status：ROHS3 Compliant
- Lead Free：Lead Free
