画像はあくまで参考です。

BPA06SB

在庫數 446

  • 1+: $2.93787
  • 10+: $2.77157
  • 100+: $2.61469
  • 500+: $2.46669
  • 1000+: $2.32707

小計金額 $2.93787

仕様 よくある質問
  • Factory Lead Time:14 Weeks
  • Mount:Surface Mount
  • Mounting Type:Surface Mount, Right Angle
  • Package / Case:DIP
  • Body Material:Polyphenylene Sulfide (PPS)
  • Actuator Material:Polyamide
  • Contact Materials:Beryllium Copper
  • ElectricalLife:1,000 Cycles
  • Voltage Rated:5VDC
  • Operating Temperature:-20°C~85°C
  • Packaging:Tube
  • Series:BPA
  • Published:2011
  • Part Status:Active
  • Moisture Sensitivity Level (MSL):1 (Unlimited)
  • Termination:Gull Wing
  • Number of Positions:6
  • Voltage - Rated DC:24V
  • Pitch:0.100 2.54mm Full
  • Orientation:Straight
  • Terminal Pitch:2.54mm
  • Depth:11.05mm
  • Current Rating:100mA
  • Contact Finish:Gold
  • Termination Style:Gull Wing
  • Actuator Type:Piano
  • Circuit:SPST
  • Contact Resistance:50mOhm
  • Max Current Rating:100mA
  • Max Voltage Rating (DC):24V
  • Mechanical Life:1,000 Cycles
  • Washable:Yes
  • Actuator Level:Raised
  • Length:0.677 17.20mm
  • Actuator Length:2.1mm
  • Height Above Board:0.274 6.95mm
  • Radiation Hardening:No
  • RoHS Status:ROHS3 Compliant
  • Lead Free:Lead Free

在庫數 446

  • 1+: $2.93787
  • 10+: $2.77157
  • 100+: $2.61469
  • 500+: $2.46669
  • 1000+: $2.32707

小計金額 $2.93787

類似スペック製品

  • BPA06SB C&K

    最低価格$2.9378691 在庫數 446

  • BPA06SBR C&K

    最低価格$4.888306 在庫數 14

  • 219-6LPST CTS Electrocomponents

    最低価格$0.7790913 在庫數 49

  • SDA06H0SB C&K

    最低価格$2.4912468 在庫數 157

  • SDA06H0SBD C&K

    最低価格$1.437204 在庫數 23
