SM6T33CA

STMicroelectronics
TVS - Diodes
DO-214AA, SMB
TVS DIODE 28.2V 59V SMB
Date Sheet

在庫數 6500

1+： $0.38568
10+： $0.36385
100+： $0.34325
500+： $0.32382
1000+： $0.30549

小計金額 $0.38568

仕様よくある質問

Lifecycle Status：ACTIVE (Last Updated: 7 months ago)
Factory Lead Time：17 Weeks
Mount：Surface Mount
Mounting Type：Surface Mount
Package / Case：DO-214AA, SMB
Number of Pins：2
Diode Element Material：SILICON
Breakdown Voltage / V：31.4V
Number of Elements：1
Reverse Stand-off Voltage：33V
Operating Temperature：-55°C~150°C TJ
Packaging：Tape & Reel (TR)
Series：SM6T, TRANSIL™
JESD-609 Code：e3
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Number of Terminations：2
Termination：SMD/SMT
ECCN Code：EAR99
Type：Zener
Terminal Finish：Matte Tin (Sn) - annealed
Applications：General Purpose
Additional Feature：UL RECOGNIZED
Capacitance：1nF
Power Rating：600W
Voltage - Rated DC：33V
Terminal Position：DUAL
Terminal Form：C BEND
Peak Reflow Temperature (Cel)：260
Time@Peak Reflow Temperature-Max (s)：30
Base Part Number：SM6T
Pin Count：2
Operating Supply Voltage：33V
Polarity：Bidirectional
Number of Channels：1
Leakage Current：200nA
Element Configuration：Single
Power Dissipation：600W
Power Line Protection：No
Current - Peak Pulse (10/1000μs)：68A 8/20μs
Max Reverse Leakage Current：200nA
Clamping Voltage：59V
Voltage - Reverse Standoff (Typ)：28.2V
Peak Pulse Current：68A
Max Surge Current：1mA
Peak Pulse Power：600W
Direction：Bidirectional
Test Current：1mA
Reverse Breakdown Voltage：31.4V
Non-rep Peak Rev Power Dis-Max：4000W
Max Breakdown Voltage：34.7V
Max Junction Temperature (Tj)：150°C
Height：2.65mm
Length：4.6mm
Width：3.95mm
REACH SVHC：No SVHC
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free

在庫數 6500

1+： $0.38568
10+： $0.36385
100+： $0.34325
500+： $0.32382
1000+： $0.30549

小計金額 $0.38568
