24AA64T-I/ST

在庫數 1677

小計金額 $0.54242

仕様よくある質問

Factory Lead Time：7 Weeks
Contact Plating：Tin
Mount：Surface Mount
Mounting Type：Surface Mount
Package / Case：8-TSSOP (0.173, 4.40mm Width)
Number of Pins：8
Memory Types：Non-Volatile
Operating Temperature：-40°C~85°C TA
Packaging：Tape & Reel (TR)
Published：2007
JESD-609 Code：e3
Pbfree Code：yes
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Number of Terminations：8
ECCN Code：EAR99
Additional Feature：DATA RETENTION > 200 YEARS; 1000000 ERASE/WRITE CYCLES GUARANTEED
Voltage - Supply：1.7V~5.5V
Terminal Position：DUAL
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Supply Voltage：2.5V
Terminal Pitch：0.65mm
Time@Peak Reflow Temperature-Max (s)：40
Base Part Number：24AA64
Pin Count：8
Supply Voltage-Max (Vsup)：5.5V
Power Supplies：2/5V
Supply Voltage-Min (Vsup)：1.7V
Interface：2-Wire, I2C, Serial
Memory Size：64Kb 8K x 8
Nominal Supply Current：3mA
Clock Frequency：400kHz
Access Time：900ns
Memory Format：EEPROM
Memory Interface：I2C
Memory Width：8
Write Cycle Time - Word, Page：5ms
Density：64 kb
Standby Current-Max：0.000001A
Serial Bus Type：I2C
Endurance：1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC)：5ms
Data Retention Time-Min：200
Write Protection：HARDWARE
I2C Control Byte：1010DDDR
Length：4.4mm
Height Seated (Max)：1.2mm
Width：3mm
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free

在庫數 1677

小計金額 $0.54242
