MS3112E14-5P

在庫數 9

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：16 Weeks
Mount：Box, Flanges, Panel
Mounting Type：Panel Mount
Mounting Feature：Flange
Shell Material：Aluminum
Insert Material：Neoprene
Body Material：Aluminium
Contact Finish Mating：Gold
Contact Materials：Copper Alloy
Voltage Rated：1kV
Operating Temperature：-55°C~125°C
Packaging：Bulk
Series：Military, MIL-DTL-26482 Series I, PT
Published：2006
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Termination：Solder Cup
Connector Type：Receptacle, Male Pins
Number of Positions：5
Color：Olive Drab
Applications：Aerospace, Communication Systems, Industrial, Instrumentation, Mass Transit, Military
Gender：Receptacle
Additional Feature：STANDARD: MIL-C-26482
Fastening Type：Bayonet Lock
MIL Conformance：YES
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Mixed Contacts：NO
Option：GENERAL PURPOSE
Total Number of Contacts：5
Orientation：N (Normal)
Shielding：Unshielded
Ingress Protection：Environment Resistant
Depth：28.57mm
Current Rating：10A
Military Standard：MIL-DTL-26482
Shell Finish：Olive Drab Chromate over Cadmium
Shell Size - Insert：14-5
Voltage - Rated AC：1kV
Approval Agency：UL
Mating Information：NO
Contact Gender：Male
Empty Shell：NO
Backshell Type：SOLID
Contact Style：Pin
Plating：Cadmium, Chromate
Wire Gauge (Max)：22 AWG
Wire Gauge (Min)：16 AWG
Length：24.33mm
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：Non-RoHS Compliant
Ratings：Environment Resistant
