97-3100A-18-1S

Amphenol Industrial Operations
Circular Connectors
Metal
Circular MIL Spec Connector 10P Sz 18 Wall Mount Socket Recept Solder
Date Sheet

在庫數 49

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：14 Weeks
Mount：Chassis, Flanges, Panel, Wall
Mounting Type：Panel Mount
Package / Case：Metal
Mounting Feature：Flange
Shell Material：Aluminum Alloy
Insert Material：Diallyl Phthalate (DAP)
Body Material：Aluminium
Backshell Material, Plating：Aluminum Alloy, Olive Drab Chromate over Cadmium
Contact Finish Mating：Silver
Contact Materials：Copper Alloy
Voltage Rated：250V
Operating Temperature：-55°C~125°C
Packaging：Bulk
Series：97
Published：2000
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Termination：Solder Cup
Connector Type：Receptacle, Female Sockets
Number of Positions：10
Color：Olive Drab
Applications：Automotive, Industrial
Gender：Receptacle
Additional Feature：STANDARD: MIL-C-5015
Fastening Type：Threaded
MIL Conformance：YES
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Mixed Contacts：NO
Option：GENERAL PURPOSE
Total Number of Contacts：10
Orientation：N (Normal)
Shielding：Unshielded
Depth：34.93mm
Current Rating：13A
Military Standard：MIL-DTL-5015
Shell Finish：Olive Drab Chromate over Cadmium
Shell Size - Insert：18-1
Approval Agency：CSA, UL
Mating Information：MULTIPLE MATING PARTS AVAILABLE
Contact Gender：Female
Empty Shell：NO
Backshell Type：SOLID
Contact Style：Socket
Environmental Characteristics：ENVIRONMENT RESISTANT
Plating：Cadmium, Chromate
Wire Gauge (Max)：22 AWG
Wire Gauge (Min)：16 AWG
Body Plating：Cadmium
Wire/Cable Gauge：16 AWG
Features：Backshell
Length：50.24mm
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：Non-RoHS Compliant
