画像はあくまで参考です。
PT01E-20-16S
-
Amphenol Industrial Operations
-
Circular Connectors
- Circular MIL Spec Connector 16P Sz 20 Cable Mnt Socket Receptacle
Date Sheet
在庫數 40
- 1+： $50.11941
- 10+： $47.28246
- 100+： $44.60610
- 500+： $42.08122
- 1000+： $39.69927
小計金額 $50.11941
仕様 よくある質問
- Factory Lead Time：16 Weeks
- Mount：Cable, Flanges, Free Hanging
- Mounting Type：Free Hanging (In-Line)
- Shell Material：Aluminum
- Insert Material：Neoprene
- Body Material：Aluminium
- Backshell Material, Plating：Aluminum, Olive Drab Cadmium
- Contact Finish Mating：Gold
- Contact Materials：Copper Alloy
- Operating Temperature：-55°C~125°C
- Packaging：Bulk
- Series：MIL-DTL-26482 Series I, PT
- Published：2006
- Part Status：Active
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Termination：Solder Cup
- Connector Type：Receptacle, Female Sockets
- Number of Positions：16
- Color：Olive Drab
- Applications：Aerospace, Industrial, Instrumentation, Mass Transit, Military
- Gender：Receptacle
- Additional Feature：STANDARD: MIL-C-26482, POLARIZATION AVAILABLE
- Fastening Type：Bayonet Lock
- MIL Conformance：YES
- DIN Conformance：NO
- IEC Conformance：NO
- Filter Feature：NO
- Mixed Contacts：NO
- Option：GENERAL PURPOSE
- Total Number of Contacts：16
- Orientation：N (Normal)
- Shielding：Unshielded
- Ingress Protection：Environment Sealed
- Current Rating：13A
- Military Standard：MIL-DTL-26482
- Shell Finish：Olive Drab Chromate over Cadmium
- Shell Size - Insert：20-16
- Voltage - Rated AC：1kV
- Approval Agency：UL
- Contact Gender：Female
- Empty Shell：NO
- Backshell Type：SOLID
- Contact Style：Socket
- Environmental Characteristics：CORROSION/ENVIRONMENT/MOISTURE RESISTANT
- Body Plating：Cadmium
- Features：Backshell
- REACH SVHC：No SVHC
- Radiation Hardening：No
- RoHS Status：Non-RoHS Compliant
- Ratings：Environment Resistant
在庫數 40
- 1+： $50.11941
- 10+： $47.28246
- 100+： $44.60610
- 500+： $42.08122
- 1000+： $39.69927
小計金額 $50.11941
