97-3100A-14S-2P

在庫數 60

  • 1+: $17.79874
  • 10+: $16.79126
  • 100+: $15.84081
  • 500+: $14.94416
  • 1000+: $14.09827

小計金額 $17.79874

仕様 よくある質問
  • Factory Lead Time:13 Weeks
  • Mounting Type:Chassis, Flanges, Panel, Wall
  • Package / Case:Metal
  • Mounting Feature:Flange
  • Shell Material:Aluminum Alloy
  • Insert Material:Diallyl Phthalate (DAP)
  • Body Material:Aluminium
  • Backshell Material, Plating:Aluminum Alloy, Olive Drab Chromate over Cadmium
  • Contact Finish Mating:Silver
  • Contact Materials:Copper Alloy
  • Insulation Materials:Plastic
  • Operating Temperature:-55°C~125°C
  • Packaging:Bulk
  • Series:97
  • Published:2004
  • Part Status:Active
  • Moisture Sensitivity Level (MSL):1 (Unlimited)
  • Termination:Solder Cup
  • Connector Type:Receptacle, Male Pins
  • Number of Positions:4
  • Color:Olive Drab
  • Applications:Automotive, Industrial
  • Gender:Male
  • Additional Feature:STANDARD: MIL-C-5015
  • Fastening Type:Threaded
  • Voltage - Rated DC:250V
  • DIN Conformance:NO
  • IEC Conformance:NO
  • Filter Feature:NO
  • Mixed Contacts:NO
  • Option:GENERAL PURPOSE
  • Current Rating (Amps):13A
  • Orientation:N (Normal)
  • Shielding:Unshielded
  • Depth:30.15mm
  • Military Standard:YES
  • Shell Finish:Olive Drab Chromate over Cadmium
  • Shell Size - Insert:14S-2
  • Voltage - Rated AC:800mV
  • Approval Agency:CSA, UL
  • Number of Contacts:4
  • Mating Information:MULTIPLE MATING PARTS AVAILABLE
  • Empty Shell:NO
  • Backshell Type:SOLID
  • Contact Style:Pin
  • Wire Gauge:16 AWG
  • Environmental Characteristics:ENVIRONMENT RESISTANT
  • Plating:Cadmium, Chromate
  • Body Plating:Cadmium
  • Features:Backshell
  • Length:37.39mm
  • REACH SVHC:No SVHC
  • Radiation Hardening:No
  • RoHS Status:Non-RoHS Compliant
  • Lead Free:Contains Lead
