142124

在庫數 5

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：8 Weeks
Contact Plating：Gold
Mount：Bulkhead, Cable, Front Side Nut, Panel
Mounting Type：Panel Mount
Package / Case：SMB
Mounting Feature：Bulkhead - Front Side Nut
Dielectric Material：Polytetrafluoroethylene (PTFE)
Body Material：Brass
Center Contact Plating：Gold
Center Contact Material：Brass
Contact Materials：Brass, Copper
Frequency(Max)：4GHz
Voltage Rated：335V
Operating Temperature：-65°C~165°C
Packaging：Bulk
Published：2001
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Termination：Solder
Connector Type：Jack, Male Pin
Max Operating Temperature：165°C
Min Operating Temperature：-65°C
Gender：Female
Fastening Type：Snap-On
Orientation：Straight
Frequency：4GHz
Housing Color：Silver
Impedance：50Ohm
Connector Style：SMB
Number of Ports：1
Body Plating：Nickel
Mating Cycles：500
Contact Termination：Solder
Includes：9 pcs - 1 Connector, 1 Contact, 1 Clamp, 1 Gasket, 2 Insulators, 1 Nut, 1 Ring, 1 Washer
Insertion Loss：0.3dB
Body Finish：Nickel
Cable Group：RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
Shield Termination：Clamp
Radiation Hardening：No
RoHS Status：RoHS Compliant
