TDA749213TR

在庫數 10000

小計金額 $0.00000

仕様よくある質問

Lifecycle Status：ACTIVE (Last Updated: 7 months ago)
Factory Lead Time：6 Weeks
Mount：Surface Mount
Mounting Type：Surface Mount
Package / Case：36-PowerFSOP (0.295, 7.50mm Width)
Number of Pins：36
Operating Temperature：0°C~70°C TA
Packaging：Tape & Reel (TR)
JESD-609 Code：e3
Part Status：Active
Moisture Sensitivity Level (MSL)：3 (168 Hours)
Number of Terminations：36
ECCN Code：EAR99
Type：Class D
Terminal Finish：Matte Tin (Sn) - annealed
Voltage - Supply：8V~26V
Terminal Position：DUAL
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Terminal Pitch：0.5mm
Base Part Number：TDA7492
Pin Count：36
Output Type：2-Channel (Stereo)
Supply Voltage-Min (Vsup)：8V
Number of Channels：2
Supply Current-Max：35mA
Output Power：50W
Bandwidth：22 kHz
Voltage Gain：33.6dB
Power Supply Rejection Ratio (PSRR)：50dB
Gain：33.6 dB
Max Output Power：50W
Max Output Power x Channels @ Load：50W x 2 @ 6 Ω
Harmonic Distortion：10%
Features：Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Length：10.3mm
Width：7.5mm
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
