TAS5719PHP

在庫數 14

小計金額 $12.99359

仕様よくある質問

Lifecycle Status：ACTIVE (Last Updated: 4 days ago)
Factory Lead Time：12 Weeks
Mounting Type：Surface Mount
Package / Case：48-PowerTQFP
Surface Mount：YES
Number of Pins：48
Power - Output (Max)：15W
Current - Supply (Nom)：34mA
Operating Temperature：0°C~85°C TA
Packaging：Tray
JESD-609 Code：e4
Pbfree Code：yes
Part Status：Active
Moisture Sensitivity Level (MSL)：3 (168 Hours)
Number of Terminations：48
ECCN Code：EAR99
Type：Class D
Terminal Finish：Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code：8542.33.00.01
Voltage - Supply：3V~3.6V
Terminal Position：QUAD
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Terminal Pitch：0.5mm
Base Part Number：TAS5719
Pin Count：48
Output Type：2-Channel (Stereo) with Stereo Headphones
Operating Supply Voltage：26V
Number of Channels：2
Output Power：15W
Bandwidth：20 kHz
Min Supply Voltage (DC)：3V
Max Output Power x Channels @ Load：15W x 2 @ 8 Ω
Voltage - Supply (Max)：3.6V
Harmonic Distortion：10%
Features：Depop, Differential Inputs, I2C, Shutdown, Thermal Protection, Volume Control
Height：1.2mm
Length：7mm
Width：7mm
Thickness：1mm
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
