TAS5731PHP

在庫數 18

小計金額 $4.09832

仕様よくある質問

Lifecycle Status：ACTIVE (Last Updated: 1 week ago)
Factory Lead Time：8 Weeks
Mounting Type：Surface Mount
Package / Case：48-PowerTQFP
Surface Mount：YES
Number of Pins：48
Operating Temperature：0°C~85°C TA
Packaging：Tray
JESD-609 Code：e4
Pbfree Code：yes
Part Status：Active
Moisture Sensitivity Level (MSL)：3 (168 Hours)
Number of Terminations：48
ECCN Code：EAR99
Type：Class D
Terminal Finish：Nickel/Palladium/Gold (Ni/Pd/Au)
Voltage - Supply：8V~21V
Terminal Position：QUAD
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Terminal Pitch：0.5mm
Base Part Number：TAS5731
Pin Count：48
Output Type：1-Channel (Mono) or 2-Channel (Stereo)
Operating Supply Voltage：21V
Supply Voltage-Max (Vsup)：3.6V
Power Supplies：3.3V
Supply Voltage-Min (Vsup)：3V
Number of Channels：2
Nominal Supply Current：20mA
Output Power：20W
Bandwidth：20 kHz
Max Output Power：41.5W
Max Output Power x Channels @ Load：41.5W x 1 @ 4 Ω; 20.9W x 2 @ 8 Ω
Harmonic Distortion：10%
Load Impedance：8Ohm
Features：Depop, Digital Inputs, I2C, I2S, Mute, Short-Circuit and Thermal Protection, Volume Control
Height：1.2mm
Length：7mm
Width：7mm
Thickness：1mm
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
