TDA7575B

在庫數 266

小計金額 $8.59997

仕様よくある質問

Lifecycle Status：ACTIVE (Last Updated: 8 months ago)
Factory Lead Time：13 Weeks
Contact Plating：Tin
Package / Case：27-Flexiwatt (Formed Leads)
Mounting Type：Through Hole
Mount：Through Hole
Number of Pins：27
Packaging：Tube
Operating Temperature：-55°C~150°C TJ
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Number of Terminations：27
ECCN Code：EAR99
Type：Class AB
HTS Code：8542.33.00.01
Max Power Dissipation：86W
Voltage - Supply：8V~18V
Terminal Position：ZIG-ZAG
Number of Functions：1
Terminal Pitch：1mm
Base Part Number：TDA7575
Pin Count：27
Output Type：1-Channel (Mono) or 2-Channel (Stereo)
Max Output Current：8A
Supply Voltage-Max (Vsup)：18V
Power Supplies：14.4V
Supply Voltage-Min (Vsup)：8V
Number of Channels：2
Power Dissipation：86W
Supply Current-Max：200mA
Output Power：40W
Common Mode Rejection Ratio：56 dB
Supply Type：Single
Input Offset Voltage (Vos)：45mV
Bandwidth：22 kHz
Voltage Gain：26dB
Gain：26 dB
Max Output Power：150W
Max Output Power x Channels @ Load：150W x 1 @ 1 Ω; 75W x 2 @ 2 Ω
Harmonic Distortion：10%
Features：Differential Inputs, I2C, Mute, Short-Circuit and Thermal Protection, Standby
RoHS Status：ROHS3 Compliant
Radiation Hardening：No
Lead Free：Lead Free
