TDA7391PDU

在庫數 41

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：13 Weeks
Mount：Surface Mount
Mounting Type：Surface Mount
Package / Case：20-SOIC (0.433, 11.00mm Width) Exposed Pad
Number of Pins：20
Operating Temperature：-40°C~150°C TJ
Packaging：Tube
Part Status：Active
Moisture Sensitivity Level (MSL)：3 (168 Hours)
Number of Terminations：20
ECCN Code：EAR99
Type：Class AB
Voltage - Supply：8V~18V
Terminal Position：DUAL
Terminal Form：GULL WING
Number of Functions：1
Base Part Number：TDA7391
Output Type：1-Channel (Mono)
Number of Channels：1
Output Power：32W
Common Mode Rejection Ratio：65 dB
Voltage Gain：30dB
Power Supply Rejection Ratio (PSRR)：60dB
Max Output Power：40W
Max Output Power x Channels @ Load：40W x 1 @ 3.2 Ω
Features：Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Height：3.55mm
Length：16mm
Width：11.1mm
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
