画像はあくまで参考です。
LB11650-E
-
ON Semiconductor
-
PMIC - Motor Drivers, Controllers
- 14-SIP Exposed Tab, Formed Leads
- IC MTR DRV BIPLR 3-5.25V 14SIPHZ
Date Sheet
在庫數 2245
- 1+： $2.03059
- 10+： $1.91565
- 100+： $1.80722
- 500+： $1.70492
- 1000+： $1.60842
小計金額 $2.03059
仕様 よくある質問
- Lifecycle Status：LAST SHIPMENTS (Last Updated: 1 month ago)
- Factory Lead Time：43 Weeks
- Mount：Surface Mount, Through Hole
- Mounting Type：Through Hole
- Package / Case：14-SIP Exposed Tab, Formed Leads
- Number of Pins：14
- Operating Temperature：-20°C~85°C TA
- Packaging：Tape & Box (TB)
- Published：2003
- JESD-609 Code：e6
- Pbfree Code：yes
- Part Status：Obsolete
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Number of Terminations：14
- Terminal Finish：Tin/Bismuth (Sn/Bi)
- Applications：General Purpose
- Additional Feature：ALSO OPERATES IN 8 TO 28V SUPPLY
- Voltage - Supply：3V~5.25V
- Terminal Position：ZIG-ZAG
- Supply Voltage：5V
- Base Part Number：LB11650
- Function：Driver - Fully Integrated, Control and Power Stage
- Number of Outputs：1
- Supply Voltage-Max (Vsup)：5.25V
- Power Supplies：524V
- Supply Voltage-Min (Vsup)：3V
- Interface：PWM
- Analog IC - Other Type：STEPPER MOTOR CONTROLLER
- Nominal Supply Current：75μA
- Output Configuration：Half Bridge (2)
- Power Dissipation：3.5W
- Supply Current-Max (Isup)：95mA
- Voltage - Load：8V~28V
- Motor Type - AC, DC：Brushed DC
- Motor Type - Stepper：Bipolar
- Length：27mm
- Width：4mm
- Radiation Hardening：No
- RoHS Status：RoHS Compliant
- Lead Free：Lead Free
在庫數 2245
- 1+： $2.03059
- 10+： $1.91565
- 100+： $1.80722
- 500+： $1.70492
- 1000+： $1.60842
小計金額 $2.03059
