MIC5259-3.3YML-TR

在庫數 55

小計金額 $1.02094

仕様よくある質問

Factory Lead Time：8 Weeks
Mount：Surface Mount
Mounting Type：Surface Mount
Package / Case：6-VDFN Exposed Pad, 6-MLF®
Number of Pins：6
Supplier Device Package：6-MLF® (2x2)
Operating Temperature：-40°C~125°C
Packaging：Tape & Reel (TR)
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Max Operating Temperature：125°C
Min Operating Temperature：-40°C
Base Part Number：MIC5259
Current - Supply (Max)：250μA
Voltage - Input (Max)：6V
Output Voltage：3.3V
Output Type：Fixed
Max Output Current：300mA
Output Configuration：Positive
Control Features：Enable
Voltage - Output (Min/Fixed)：3.3V
Number of Regulators：1
Protection Features：Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)：150μA
Voltage Dropout (Max)：0.55V @ 300mA
PSRR：65dB ~ 53dB (10Hz ~ 10kHz)
Dropout Voltage：300mV
Min Current Limit：350mA
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free

在庫數 55

小計金額 $1.02094
