HWS300-15

在庫數 2096

小計金額 $301.75603

仕様よくある質問

Lifecycle Status：PRODUCTION (Last Updated: 2 months ago)
Factory Lead Time：17 Weeks
Mount：Chassis, Chassis Mount, Panel
Mounting Type：Chassis Mount
Package / Case：300
Number of Pins：7
Weight：389.999995g
Power - Output (Max)：330W
Operating Temperature：-10°C~70°C With Derating
Series：HWS (300W)
Published：2005
Size / Dimension：6.50Lx2.40W x 3.23 H 165.1mmx61.0mmx82.0mm
Part Status：Active
Moisture Sensitivity Level (MSL)：Not Applicable
Type：Enclosed, Conformal Coated
Applications：ITE (Commercial)
Power Rating：330W
Max Power Dissipation：300W
Depth：60.96mm
Current Rating：22A
Number of Outputs：1
Approval Agency：CE
Efficiency：85%
Voltage - Isolation：3kV
Current - Output (Max)：22A
Current - Output：22A
Output Power：330W
Voltage - Output：15V
Min Input Voltage：85V
Max Input Voltage：265V
Current - Output 1：22A
Nominal Output Voltage：15V
Min Input Voltage (AC)：85V
Max Input Voltage (AC)：265V
Features：Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Remote Sense, Universal Input
Height：82.042mm
REACH SVHC：Unknown
Radiation Hardening：No
RoHS Status：RoHS Compliant
