ADS8504IBDW

Texas Instruments
Data Acquisition - Analog to Digital Converters (ADC)
28-SOIC (0.295, 7.50mm Width)
IC ADC 12BIT 250KSPS 28-SOIC
Date Sheet

在庫數 58

1+： $19.74933
10+： $18.63144
100+： $17.57683
500+： $16.58192
1000+： $15.64332

小計金額 $19.74933

仕様よくある質問

Factory Lead Time：6 Weeks
Contact Plating：Gold
Mounting Type：Surface Mount
Package / Case：28-SOIC (0.295, 7.50mm Width)
Surface Mount：YES
Number of Pins：28
Power Dissipation (Max)：100mW
Current - Supply (Nom)：10mA
Operating Temperature：-40°C~85°C
Packaging：Tube
JESD-609 Code：e4
Pbfree Code：yes
Part Status：ACTIVE (Last Updated: 1 week ago)
Moisture Sensitivity Level (MSL)：2 (1 Year)
Number of Terminations：28
ECCN Code：EAR99
Voltage - Supply：5V
Terminal Position：DUAL
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：260
Number of Functions：1
Base Part Number：ADS8504
Polarity：Bipolar
Power Supplies：5V
Configuration：S/H-ADC
Number of Channels：1
Power Dissipation：70mW
Number of Bits：12
Input Type：Single Ended
Architecture：SAR
Converter Type：ADC, SUCCESSIVE APPROXIMATION
Supply Type：Analog, Digital
Reference Type：External, Internal
Data Interface：Parallel
Resolution：1.5 B
Sampling Rate：250 ksps
Voltage - Supply, Analog：5V
Number of Analog In Channels：1
Sampling Rate (Per Second)：250k
Output Bit Code：2'S COMPLEMENT BINARY
Power Consumption：155mW
Integral Nonlinearity (INL)：0.45 LSB
Sample and Hold / Track and Hold：SAMPLE
Conversion Rate：250 ksps
Ratio - S/H:ADC：1:1
Signal to Noise Ratio (SNR)：73 dB
Max Supply Voltage (DC)：5.25V
Differential Nonlinearity：0.45 LSB
Min Supply Voltage (DC)：4.75V
Voltage - Supply (Max)：5.25V
Voltage - Supply (Min)：4.75V
Spurious-free dynamic range (SFDR)：94 dB
Height：2.65mm
Length：17.9mm
Width：7.5mm
Thickness：2.35mm
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
