画像はあくまで参考です。
MAX4530EPP
-
Maxim Integrated
-
Interface - Analog Switches, Multiplexers, Demultiplexers
- 20-DIP (0.300, 7.62mm)
- IC MULTIPLEXER 8X1 20DIP
Date Sheet
在庫數 0
小計金額 $0.00000
仕様 よくある質問
- Mount：Through Hole
- Mounting Type：Through Hole
- Package / Case：20-DIP (0.300, 7.62mm)
- Operating Temperature：-40°C~85°C TA
- Packaging：Tube
- Published：2001
- JESD-609 Code：e0
- Pbfree Code：no
- Part Status：Obsolete
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Number of Terminations：20
- ECCN Code：EAR99
- Resistance：75Ohm
- Peak Reflow Temperature (Cel)：240
- Number of Functions：1
- Supply Voltage：5V
- Terminal Pitch：2.54mm
- Reach Compliance Code：not_compliant
- Time@Peak Reflow Temperature-Max (s)：20
- Base Part Number：MAX4530
- Pin Count：20
- JESD-30 Code：R-PDIP-T20
- Qualification Status：Not Qualified
- Power Supplies：3/5/+-5V
- Number of Channels：8
- Number of Circuits：1
- Throw Configuration：SP8T
- Logic Function：Multiplexer
- Voltage - Supply, Single/Dual (±)：2V~12V ±2V~6V
- Supply Type：Dual, Single
- Neg Supply Voltage-Nom (Vsup)：-5V
- On-State Resistance (Max)：75Ohm
- Multiplexer/Demultiplexer Circuit：8:1
- Off-state Isolation-Nom：65 dB
- Current - Leakage (IS(off)) (Max)：1nA
- Channel Capacitance (CS(off), CD(off))：3pF 15pF
- On-state Resistance Match-Nom：1Ohm
- Switch Time (Ton, Toff) (Max)：150ns, 100ns
- Charge Injection：1.5pC
- Channel-to-Channel Matching (ΔRon)：1 Ω
- Switching：BREAK-BEFORE-MAKE
- Signal Current-Max：0.02A
- Height Seated (Max)：4.572mm
- Width：7.62mm
- RoHS Status：Non-RoHS Compliant
- Lead Free：Contains Lead
