SSW-134-02-G-D

Samtec Inc.
Rectangular Connectors - Headers, Receptacles, Female Sockets
CONN RCPT .100 68POS DUAL GOLD
Date Sheet

在庫數 10

小計金額 $0.00000

仕様よくある質問

Mount：Through Hole
Mounting Type：Through Hole
Contact Shape：Square
Housing Material：Plastic
Contact Finish Mating：Gold
Contact Materials：Phosphor Bronze
Insulation Materials：Liquid Crystal Polymer (LCP)
Operating Temperature：-55°C~125°C
Packaging：Bulk
Series：SSW
Published：2000
JESD-609 Code：e4
Pbfree Code：yes
Part Status：Active
Moisture Sensitivity Level (MSL)：Not Applicable
Termination：Solder
Connector Type：Receptacle
Number of Positions：68
Number of Rows：2
Gender：Female
Additional Feature：TIGER BUY CONTACT
Fastening Type：Push-Pull
Voltage - Rated DC：655V
MIL Conformance：NO
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Contact Type：Forked
Mixed Contacts：NO
Option：GENERAL PURPOSE
Current Rating (Amps)：5.7A per Contact
Insulation Height：0.335 8.51mm
Style：Board to Board or Cable
Number of Positions Loaded：All
Pitch - Mating：0.100 2.54mm
Number of Conductors：ONE
Reference Standard：UL, CSA
Voltage - Rated AC：465V
Reliability：COMMERCIAL
Row Spacing - Mating：0.100 (2.54mm)
Contact Length - Post：0.194 4.93mm
Number Of PCB Rows：2
Lead Pitch：2.54mm
PCB Contact Pattern：RECTANGULAR
Mating Information：MULTIPLE MATING PARTS AVAILABLE
Body Breadth：0.195 inch
UL Flammability Code：94V-0
Housing Color：Black
Body Depth：0.335 inch
Contact Resistance：10mOhm
Polarization Key：POLARIZED HOUSING
Durability：100 Cycles
Height：8.51mm
Length：86.9mm
Width：4.95mm
Contact Finish Thickness - Mating：20.0μin 0.51μm
Contact Finish Thickness - Post：3.00μin 0.076μm
Material Flammability Rating：UL94 V-0
RoHS Status：ROHS3 Compliant
Lead Free：Lead Free
