MS3106F20-17P
-
Amphenol Industrial Operations
-
Circular Connectors
- AMPHENOL MS3106F20-17P Circular Connector, MIL-DTL-5015 Series, Straight Plug, 6, Solder Pin, Threaded, 20-17
Date Sheet
在庫數 2693
小計金額 $0.00000
仕様 よくある質問
- Factory Lead Time：16 Weeks
- Mount：Free Hanging
- Mounting Type：Free Hanging (In-Line)
- Shell Material：Aluminum Alloy
- Insert Material：Neoprene
- Body Material：Aluminium
- Backshell Material, Plating：Aluminum Alloy, Olive Drab Chromate over Cadmium
- Contact Finish Mating：Silver
- Contact Materials：Copper Alloy
- Operating Temperature：-55°C~125°C
- Packaging：Bulk
- Series：Military, MIL-DTL-5015
- Published：2005
- Part Status：Active
- Moisture Sensitivity Level (MSL)：1 (Unlimited)
- Termination：Solder Cup
- Connector Type：Plug, Male Pins
- Number of Positions：6
- Color：Olive Drab
- Applications：Marine, Military
- Gender：Male
- Fastening Type：Threaded
- Orientation：N (Normal)
- Shielding：Unshielded
- Ingress Protection：Environment Resistant
- Reach Compliance Code：unknown
- Military Standard：MIL-DTL-5015
- Shell Finish：Olive Drab Chromate over Cadmium
- Shell Size - Insert：20-17
- Contact Style：Pin
- Body Plating：Cadmium
- Cable Opening：0.656 (16.66mm)
- Features：Backshell, Cable Clamp, Coupling Nut
- REACH SVHC：No SVHC
- RoHS Status：Non-RoHS Compliant
- Ratings：Environment Resistant
