E-TDA7391PDTR

在庫數 264

小計金額 $2.86148

仕様よくある質問

Factory Lead Time：13 Weeks
Lifecycle Status：ACTIVE (Last Updated: 7 months ago)
Package / Case：20-SOIC (0.433, 11.00mm Width) Exposed Pad
Mounting Type：Surface Mount
Mount：Surface Mount
Number of Pins：20
Series：Automotive
Packaging：Tape & Reel (TR)
Operating Temperature：-40°C~150°C TJ
JESD-609 Code：e3
Part Status：Active
Moisture Sensitivity Level (MSL)：3 (168 Hours)
Number of Terminations：20
ECCN Code：EAR99
Type：Class AB
Terminal Finish：Tin (Sn)
HTS Code：8542.33.00.01
Max Power Dissipation：32W
Voltage - Supply：8V~18V
Terminal Position：DUAL
Terminal Form：GULL WING
Peak Reflow Temperature (Cel)：245
Number of Functions：1
Terminal Pitch：1.27mm
Time@Peak Reflow Temperature-Max (s)：30
Base Part Number：TDA7391
Pin Count：20
Output Type：1-Channel (Mono)
Operating Supply Voltage：15V
Supply Voltage-Max (Vsup)：18V
Power Supplies：14.4V
Supply Voltage-Min (Vsup)：8V
Number of Channels：1
Power Dissipation：32W
Output Power：32W
Common Mode Rejection Ratio：65 dB
Supply Type：Single
Bandwidth：22 kHz
Voltage Gain：30dB
Gain：30 dB
Max Output Power：40W
Input Bias Current：10μA
Max Output Power x Channels @ Load：40W x 1 @ 3.2 Ω
Features：Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
Width：11mm
Height Seated (Max)：3.5mm
Length：15.7mm
RoHS Status：ROHS3 Compliant
Radiation Hardening：No

在庫數 264

小計金額 $2.86148
