MS3100F24-5P

Amphenol Industrial Operations
Circular Connectors
AMPHENOL MS3100F24-5P Circular Connector, MIL-DTL-5015 Series, Wall Mount Receptacle, 16, Solder Pin, Threaded, 24-5
Date Sheet

在庫數 2845

小計金額 $0.00000

仕様よくある質問

Factory Lead Time：16 Weeks
Mount：Flanges, Panel, Wall
Mounting Type：Panel Mount
Mounting Feature：Flange
Shell Material：Aluminum Alloy
Insert Material：Neoprene
Body Material：Aluminium
Backshell Material, Plating：Aluminum Alloy, Olive Drab Chromate over Cadmium
Contact Finish Mating：Silver
Contact Materials：Copper Alloy
Operating Temperature：-55°C~125°C
Packaging：Bulk
Series：Military, MIL-DTL-5015
Published：2005
Part Status：Active
Moisture Sensitivity Level (MSL)：1 (Unlimited)
Termination：Solder Cup
ECCN Code：EAR99
Connector Type：Receptacle, Male Pins
Number of Positions：16
Color：Olive Drab
Applications：Marine, Military
Gender：Receptacle
Additional Feature：STANDARD: MIL-C-5015, COMPATIBLE CONTACTS: 10-40569; 10-40599
HTS Code：8536.69.40.20
Fastening Type：Threaded
MIL Conformance：YES
DIN Conformance：NO
IEC Conformance：NO
Filter Feature：NO
Mixed Contacts：NO
Option：GENERAL PURPOSE
Total Number of Contacts：16
Orientation：N (Normal)
Shielding：Unshielded
Ingress Protection：Environment Resistant
Military Standard：MIL-DTL-5015
Shell Finish：Olive Drab Chromate over Cadmium
Shell Size - Insert：24-5
Empty Shell：NO
Backshell Type：SOLID
Contact Style：Pin
Body Plating：Cadmium
Cable Opening：0.781 (19.84mm)
Features：Backshell, Cable Clamp
REACH SVHC：No SVHC
Radiation Hardening：No
RoHS Status：Non-RoHS Compliant
Ratings：Environment Resistant
